Purple Translucent Fine Line Masking Tape

Part No. 1113
JTAPE Purple Translucent Fine Line Masking Tape is highly flexible and conformable, making it ideal for following contours and tight curves.
Clear
Find a distributor
Enquire Now Find a Jobber

Description

JTAPE Purple Translucent Fine Line Masking Tape features a newly-formulated translucent backing that lets users see through to the surface below.

Offering an increased grab over other fine line tapes, Purple Translucent Fine Line Masking Tape reduces the chance of lifting from difficult-to-mask substrates, allowing the tape to adhere to a wide variety of surfaces.

After automotive paint application, it can be cleanly removed, leaving a defined line with no adhesive residue. It’s also heat-resistant to temperatures up to 150°C/302°F for 1 hour.

Our Purple Translucent Fine Line Masking Tape is supplied in 55m lengths, with a choice of widths ranging between 1mm – 25mm. Other sizes available upon request.

KEY FEATURES

  • Translucent backing improves visibility to the surface below
  • Increased grab over other fine line tapes to reduce the chance of lifting
  • Highly flexible and conformable to follow contours and tight curves
  • Temperature resistant up to 150°C/302°F for use in high bake ovens
  • Safe to use with water, solvent and enamel-based paints to suit a variety of applications
  • Prevents bleeding, creeping and spidering for a sharp, defined paint line every time
  • Can be cleanly removed, leaving no adhesive residue
  • Suitable for all types of automotive, marine, aerospace decorative and industrial paint systems
  • Offers short-term UV resistance

BEST FOR

  • Contrast colours/colour separation
  • OEM
  • Plastic parts
  • Painted and non-painted surfaces
  • Striping
  • Customising

SIZES

  • 1/16″ x 180′
  • 1/8″ x 180′
  • 1/4″ x 180′
  • 3/8″ x 180′
  • 1/2″ x 180′

TECHNICAL SPECIFICATIONS

Carrier

PVC
Adhesive

Rubber-based
Color

Translucent Purple
Thickness

130µm / 0.130mm (±10%)
Peel Adhesion

8N/25mm [ASTM-D1000]
Elongation at Break

>230%
Tensile Strength

>37N/cm [ASTM-D1000]
Temperature Resistance

Up to 150⁰C (302⁰F) for 1 hour

TRANSLUCENT BACKING

Provides visibility through to the surface below, ideal when following contours, tight curves or working with highly complex designs.

INCREASED GRAB

Reduces the risk of lifting on difficult-to-mask substrates and avoids issues such as creeping or bleeding to create crisp defined lines.

DOWNLOADS

Product Information Sheet

Download

Technical Data Sheet

Download

FREQUENTLY ASKED QUESTIONS

Can you use Purple Translucent Fine Line Tape for pinstriping?

Thanks to the various widths – including bespoke widths - Purple Translucent Fine Line Tape is perfect for pinstriping and creating unique automotive paint jobs.

Does Purple Translucent Fine Line Tape leave adhesive residue?

Purple Translucent Fine Line Tape can be removed without leaving any adhesive residue. After baking and allowing the clear coat to dry fully, simply peel it away from the surface for a residue-free finish.

What is the temperature resistance of Purple Translucent Fine Line Tape?

JTAPE Purple Translucent Fine Line Tape offers temperature resistance up to 150°C/302°F for up to an hour.

What surfaces can Purple Translucent Fine Line Tape be used on?

It can be used on a wide variety of surfaces, including plastics and metals, so it’s great for use across industries such as aerospace, manufacturing and decorating – in addition to the automotive industry.
